Scott Voltage Eride 920
The Voltage 920 is our long-travel electric mountain bike, featuring a carbon front triangle and an aluminum rear triangle. It’s designed for riders who want the thrills of a high-end MTB without the sky-high price tag. Lightweight and capable, with 160 mm of front travel and 155 mm at the rear, plus an upgraded high-performance motor, the Voltage 920 is the ideal e-MTB for long rides, hardcore descents and demanding trails.
Scott Voltage Eride 920Large / Black / Gold
Sale price9,799.99$
Specifications
SpecificationsFrame
Carbon HMF Main Frame, Alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link Kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline
Suspension
Travel Front: 150mm, Rear: 155mm
Fork
Marzocchi Z2 Air Rail, Sweep Adj, 15x110mm QR axle, tapered steerer, 44mm offset, Reb. Adj., Lockout, 150mm travel
Rear shock
X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 155-100-Lockout, T185X55mm
Remote system
SCOTT TracLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
Motor
TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25km/h, US: 20mph
Battery
TQ Internal 360Wh + TQ Range Extender 160Wh
Display / Remote
TQ HPR, Bluetooth, ANT+, Dedicated Smartphone app
Charger
TQ 100-240V-4A
Rear derailleur
SRAM Eagle 70 Transmission 12 Speed
Shifters
SRAM Eagle 70 Shifter
Crank
Praxis Alloy
Chainguide
*thirteen, e*spec Slider
Chainring
Praxis alloy spider, SRAM Eagle Transmission 34T chainring
Chain
SRAM CN Eagle 70 Transmission
Cassette
SRAM Eagle XS 1270 Transmission 10-52
Brakes
SRAM DB4 Stealth 4-Piston Disc
Rotors
SRAM HS2 Rotors F&R 200mm
Handlebar
Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm, Syncros Endurance lock-on grips
Stem
Syncros AM 2.0, 4° rise, 6061 Alloy, 31.8mm, 1 1/8"
Seatpost
Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm, S size 140mm, M size 180mm, L size 180mm, XL size 210mm
Saddle
Syncros Tofino 2.0 Regular
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, ±0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Hubs
Front: Formula CL-811, 15x110mm | Rear: Formula CL-148S, 12x148mm
Spokes
Stainless Black 15G, 1.8mm
Rims
Syncros X-30S, 32H, 30mm, Sleeve Joint, Tubeless ready
Tires
Front: Maxxis Assegai 2.5", Rear: Maxxis Dissector 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra
Approx. weight
19.8 kg Tubeless setup without RE (1.1kg) / 43.65 lb
Max. system weight
130 kg (bike + rider + equipment + luggage)
