Frame
Alloy frame, Virtual 4 Link (VLK) kinematics, 27.5" and 29" compatible, adjustable geometry, Boost 148x12 mm, 140 mm travel, Bosch Gen4 compatible, removable integrated battery, E2 tapered head tube, center kickstand mount, Range Booster ready
Fork
Marzocchi Z2 Air eMTB+, Rail 3, 3 modes, 15x110 mm axle, tapered steerer, 44 mm offset, rebound adjustment, lockout, 140 mm travel
Rear shock
X-Fusion NUDE Trunnion, custom SCOTT tune with adjustable geometry, 3 modes (Lockout / Traction Control / Descend), rebound adjustment, 140–90 mm travel, 185x50 mm
System / Battery
SCOTT TwinLoc 2 technology (suspension and dropper post remote), 3 modes, Bosch PowerTube 625 Wh battery
Motor
Bosch Performance Line CX, assistance up to 25 km/h (EU) / 20 mph (INT)
Tires
Maxxis Rekon, 29 x 2.6", 60 TPI, EXO casing, Dual Compound
Brakes
SRAM DB8, 4-piston hydraulic disc brakes
Rear derailleur
SRAM NX Eagle, 12-speed
Crankset
FSA CK-320, 165 mm crank arms, 34T chainring, SRAM SX Eagle Single Click shifter
Cassette
SRAM PG-1210, 11–50T
Chain
SRAM SX Eagle
Handlebar
Syncros Hixon 2.0 Rise, 6061 double-butted alloy, 20 mm rise, 8° backsweep, 740 mm width, Syncros Comfort lock-on grips
Stem
Syncros FL2.0, 6061 alloy, 31.8 mm, 6° angle, with L-spacer and top cap
Headset
Syncros ER2.0 Press Fit E2, tapered 1.5" - 1 1/8", OD 52/62 mm, ID 44/56 mm
Seatpost
Syncros Duncan Dropper 2.5, 31.6 mm (S: 100 mm, M: 125 mm, L: 150 mm)
Saddle
Syncros Capilano
