CARVE 16"

Colors:

Gloss Dusk Navy

Frame Material:

100% Hi-Ten Steel

Toptube Length:

16.5"

Fork:

Kink Stryker 4130 Chromoly Steerer
Tapered Fork Legs

Bars:

Kink Tiger CC 7” 100% Hi-Ten Steel

Grips:

Mission Helix Mini

Barends:

Mission Phase Plug Style

Stem:

Mission Topload 40mm

Headset:

Mission Sealed Integrated (41.8 x 45)

Brake Lever:

Mission Mini

Brake Cable:

Mission L1 Linear

Brakes:

Mission Cease V2

Cranks:

Mission Triumph 3pc Tubular Chromoly 140mm – 8 Spline

Bottom Bracket:

Sealed Mid 19mm

Pedals:

Kink Hemlock

Chain:

Mission 410

Sprocket:

Mission Rank 25T

Front Hub:

Mission Covert Unsealed 3/8? Axle

Rear Hub:

Mission Function Semi-Sealed Cassette 14mm

Driver:

9T

Front Rim:

Mission X7

Rear Rim:

Mission X7

Seat:

Mission LaForce Mini Combo

Seat Post:

Mission Combo Steel Post

Seat Clamp:

Mission Slim

Front Tire:

Mission Tracker 16x2.4"

Rear Tire:

Mission Tracker 16x2.4"

Gyro Tabs:

Tapped for Tabs

Weight:

22lb 12oz

Toptube Length:

16.5"

Chainstay Length:

11.25"

Headtube Angle:

74.5°

Seattube Angle:

71°

Standover Height:

6.75?

Bottom Bracket Height:

9.75"

Fork Offset:

32mm
